Saginomiya SYS-C103X24A dual scale

  • Type SYS is standard model. Reliable performance, and
    long life products.
  • Applicable for R410A (SYS – C140X0)
  • Scale plate with significantly clear visibility
  • Compact and light weight
  • Fluid temperature: －20 to 120°C
  • Ambient temperature: －20 to 70°C
$30.00 No tax
Add to wishlist
Share
Description

Compact size smallest and lightest in the industry.
Scale plate with significantly clear visibility.
For universal application.

Specifications
SYS-C103X24A
Connection
1/4"
Refrigerant
R22
R134a
R404a
R407C
Reset function
not present
Diff.press.setting range [Max]
0.2MPa (2kgf/cm2)
Diff.press.setting range [Min]
0.035MPa (0.35kgf/cm2)
Range [Max]
0.3MPa (3kgf/cm2)
Range [Min]
−0.06MPa (−50cmHg)
Resources
SYS Download (64.62k)
